Qorvo UF4SC120023B7S G4 FET de carburo de silicio (SiC)

Written by: INCB
Category: Nuevos Componentes , Industria y Noticias

Los FET de carburo de silicio (SiC) Qorvo UF4SC120023B7S G4 son dispositivos de 1200 V y 23 mΩ basados ​​en una configuración de circuito de 'código' única. En esta configuración, un JFET de SiC normalmente encendido se empaqueta con un MOSFET de Si, lo que produce un dispositivo FET de SiC normalmente apagado. Las características estándar de accionamiento de puerta del dispositivo permiten el uso de controladores de puerta disponibles en el mercado, por lo que requieren un rediseño mínimo al reemplazar IGBT de Si, dispositivos de superunión de Si o MOSFET de SiC. Disponible en un paquete D2PAK-7L que ahorra espacio (que permite el montaje automatizado), estos dispositivos exhiben una carga de puerta ultrabaja y características excepcionales de recuperación inversa. Los FET de SiC Qorvo UF4SC120023B7S G4 son ideales para conmutar cargas inductivas y aplicaciones que requieren un accionamiento de puerta estándar.

Clique aquí para ver las hojas de datos
