Kinetic Technologies KTE7200 Receptor de alimentación inalámbrico

Written by: INCB
Category: Nuevos Componentes , Industria y Noticias

El receptor de energía inalámbrico KTE7200 de Kinetic Technologies es una solución robusta de un solo chip que cumple con los estándares WPC/Qi v1.2 diseñada para dispositivos de bajo consumo. Este dispositivo está optimizado para dispositivos de bajo costo y baja potencia con bobinas pequeñas, pocos componentes y diseños de PCB de bajo costo. El KTE7200 exhibe un diseño basado en microcontrolador, configurable opcionalmente mediante memoria OTP, capacidades de programación de resistencias y/o control mediante interfaz I²C. Este receptor de energía inalámbrico altamente integrado incluye ROM de 8k, memoria OTP de 8k, un regulador LDO con OVP/OCP/RCP y salida de CC regulada con precisión. Las aplicaciones típicas incluyen estuches para auriculares, ratones, dispositivos y accesorios de IoT, productos de cuidado personal, juguetes, otros equipos que funcionan con baterías y dispositivos sin baterías que utilizan únicamente energía inalámbrica.

Clique aquí para ver las hojas de datos
