Micro receptor para alcance de 11 metros (CIR22978S)

Written by: Newton C. Braga
Category: Banco de circuitos



Este receptor para la banda ciudadana fue encontrado en la revista Radio Electrónica de junio de 1952. Ya estaban disponibles los primeros transistores de RF y esta es una aplicación para ensamblar en un artículo de la publicación.
