Alarma para Auto 555 (CIR19121S)

Written by: Newton C. Braga
Category: Banco de circuitos



Encontramos este circuito en una documentación antigua de Mullard (Philips) sobre el circuito integrado 555 y 556 (doble 555). El relé debe ser de 12 V con contactos que admitan la corriente de la bocina.



Alarma para Auto 555
Alarma para Auto 555
