Regulador de corriente constante (CIR15950S)

Written by: Newton C. Braga
Category: Banco de circuitos



    Este circuito para corrientes de 500 mA a 1.5 A se encontró en una GHam Radio de los años 90. R4 determina la corriente en la carga bajo prueba. Los transistores deben estar equipados con radiadores.



Regulador de corriente constante
Regulador de corriente constante
