Regulador de 5 a 20 V con 1 A (CIR7632S)

Written by: Newton C. Braga
Category: Banco de circuitos



    Este circuito estabilizador utiliza diodo zener y amplificador operacional para determinar la tensión de salida, ajustada en un potenciómetro doble de 4k7. El circuito es de una documentación técnica de los años 70.
